Sesam 800 Large 99

A rugged, advanced transmitter that can control up to 999 doors, gates or booms

Sesam 800 Large 99 is our most advanced transmitter that can control up to 999 doors. The Large 99 supports group ID coding and can be used with the MC Manager configuration tool that simplifies the installation, configuration and maintenance of large-scale installations. The Large 99 lets you set the operating range for extra security and can also be protected with a 4-figure PIN code. The transmitter is very rugged and is safety classed to IP67.

Application
Technical data
Number of functions3
Temperature range-25 to +55°C
Radio frequency869.8 MHz
Output power5 mW
Battery3V (2xAA)
Power consumption30 mA during transmission
Protection classIP67
Dimensions120 x 75 x 30 mm
Weight200 g
